Coastal Pipe USA, LLC.
Coastal Pipe USA has been serving the oil & gas industry for over 25 years. We offer proprietary tool joint connections engineered for the most demanding drilling applications.
About Us
Coastal Pipe USA, LLC. specializes in providing proprietary tool joint connections that meet the rigorous demands of high-performance drilling applications. Our innovative solutions ensure optimal performance and reliability, enabling our clients to achieve exceptional results in their drilling operations.
With international supplier relationships, Coastal Pipe USA can provide high quality, high performance drill pipe that meets the latest API standards and beyond — backed by a full engineering and technical services team.
Learn MoreAll products meet or exceed the latest API Standards, with precision threading per API Spec 7-1.
Our CP Connection delivers extended life, enhanced performance, and interchangeability with non-patented connections.
In-house engineering with 2D/3D CAD, ANSYS FEA, machine shop facilities, and worldwide service support.
Grade grooves and hardbanding applied per customer specification — inlaid or raised.
Empower Your Business
Coastal Pipe USA, LLC. offers a proprietary tool joint connection for high-demanding drilling applications. Designed for extended life and enhanced performance characteristics, and interchangeability with most non-patented drilling connections.
These connections were developed using the latest 3D design tools and materials science technology. Our connections are designed and tested within the company's high quality engineering standards and tested to conform to worldwide industry standards.
Developed using the latest 3D CAD design tools and materials science technology for precision engineering.
Compatible with most non-patented drilling connections for flexible deployment across your drill string.
Conforms to worldwide industry standards — tested and validated to Coastal Pipe's engineering standards.
Performance Drill Pipe
Inertia welded drill pipe from 2-3/8" OD through 6-5/8" OD, meeting the latest API Standards with tight dimensional tolerances and high-performance tool joints.
Manufactured from tubes that allow for tight dimensional tolerances, providing a 95% minimum wall in every tube — up to 100% more wall wear than API premium class.
Manufactured to offer unmatched reliability and efficiency, with traceability maintained through permanent identification numbers traceable to original mill testing.
Integral and welded HWDP with higher yield material strength, extending service life while providing higher torque and tensile loads throughout the drill string.
Precision-trepanned for true bores, made from 4145-modified alloy bars, quenched and tempered full length — drifted to API specification with quality-assured connections.
Manufactured from 4140/4145/4130 M7 drill collar bar material with atmospheric heat treatment to API Spec 7-1. Any type or thread combination available, 12"–48" OAL.
Integral pup joints manufactured from solid bars, heat treated to drill collar specifications. Available in 5', 10', 15', and 20' lengths to match standard drill pipe dimensions.
Performance Drill Pipe
| Diameter (in.) | Min. Yield (psi) | Min. Tensile (psi) | Min. BHN |
|---|---|---|---|
| 3-1/8 thru 6-7/8 | 110,000 | 140,000 | 285 |
| 7 thru 11 | 100,000 | 135,000 | 285 |
Material and process traceability are maintained for each Drill Collar. Every collar receives a permanent identification number through its manufacturing process, traceable to the original mill testing.
Material is heat treated full length to guarantee mechanical properties meet or exceed API Spec 7-1. Hardness is maintained within 285–341 BHN, with Charpy V-Notch testing minimum 40 ft-lbs at 70°F one inch below the surface.
All new threads are hot phosphate coated to aid in reducing galling and adhesion of the thread compound.
As needed on connections of NC-38 and up, stress relief features on both pin and box connections can be machined.
Performance Drill Pipe
Coastal Pipe USA, LLC. provides integral and welded heavy weight drillpipe with typical or higher yield material strength that provides enhanced performance on the tool joints, extending the life of the pipe and maximizing performance throughout the string.
The higher yield material aids in providing higher torque and tensile loads, minimizing any added weight throughout the drill string.
Drill pipe undergoes cyclic tensile and compressive stresses during operations. Cold rolling the thread roots on every piece reduces this stress and prevents pipe failure.
All pipe body is manufactured to API standards. Full traceability is maintained with a permanent identification number traceable to original mill testing.
| Min. Yield Strength (psi) | Min. Tensile Strength (psi) |
|---|---|
| 120,000 | 140,000 |
| 130,000 | 150,000 |
Engineering & Technical Services
Coastal Pipe USA, LLC. employs an engineering department with wide-ranging experience in manufacturing, design, and design testing, utilizing innovative technology methods of design. The approach is based on specified customer requirements, feedback, and industry needs — either by modifying existing products or designing new technology.
All designs are validated through virtual and physical testing before delivery to the customer. Our engineering personnel have numerous hours of field experience and failure analysis.
Finite Element Analysis is used for understanding component performance under specific boundaries or loading conditions — without requiring a physical prototype.
Get in Touch
Coastal Pipe USA, LLC. provides New and Used Inertia Welded drill pipe from 2-3/8" OD through 6-5/8" OD; meeting the latest API Standards.
